Quick Details

  • Type: Inkjet Printer
  • Condition: New
  • Plate Type: Flatbed Printer
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Yueda
  • Model Number: YD3200-KC roll to roll pvc UV printer
  • Usage: Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer, Tube Printer, roll to roll pvc UV printer
  • Automatic Grade: Automatic
  • Color & Page: Multicolor
  • Voltage: 110-220V 50*60HZ
  • Gross Power: 7500W
  • Dimensions(L*W*H): 4500*2100*1700mm
  • Weight: 1600KGS
  • Certification: CE, SGS
  • After-sales Service Provided: Overseas service center available
  • Keyword: roll to roll pvc UV printer
  • Print head: KM1024i
  • contact information: +86 13925228627 Alia
  • Number of nozzles: Single row 4,5,6,7,8
  • Skype id: alia_printer
  • color system: C,M,Y,K,LC,LM (Optional)
  • Printer size: 4500*2100*1700mm
  • Print width: 3200mm
  • Print height: 50 mm
  • Image Format: PDF,JPEG,TIFF,EPS,AI etc

Packaging & Delivery

Packaging Details: wooden case Package



        Super high speed 3.2M roll to roll pvc UV printer with factory price









YD3200-KC Hybrid UV Printer printer printing good effect and more outstanding,welcome to visit our factory to see our actual printing effect.


banner Printing sample


PVC printing sample







Below is our factory video,pls check it,if you think this is best for you,pls contact Alia.whatsapp/wechat: 0086 13925228627


skype: alia_printer







YD3200-KC hybrid UV Printer adopts original imported KM1024i(14pl) print head, and it can print onto super huge flex materials which maximum print width 3200mm and thickness within 50mm. The materials including paper, PVC, plastics, leather, film,PP, banner and so on. the print speed is fast and can achieve mass production.


Application fields:


Rigid materials:glass,ceramic,metal plate,wood,data plate.acrylic panel,KT board,PVC sheet,melamine sheet,marble board,etc.

Flexible materials: paper, PVC, plastics, leather, film,PP, banner,etc.




1. Internal heated industrial print head:

Brand new gray-scale degree KM1024i internal heated industrial print head, gray scale KM1024i (14pl 12kHz) industrial print head, YD3200-KC is widely used in printing industry like Large-scale outdoor advertising . Super slim and space-saving shape of the print head improves print quality and makes the printer design more exquisite. 4-8 pieces of KM1024i heads you can choose. The print resolution is high, the print speed is fast, the ink droplet is more concentrated and the colors are brighter.



The machine structure is reasonable, the whole steel frame structure adopt tempering treatment materials, stable and reliable, good toughness, high strength, wear-resisting, anti-collision anti-deformation, that protect the printers from deformation caused by the long distance transportation and shipping jounce.


Whole steel frame structure tempering treatment,which adopt dual guide rail steel frame structure,print head can be more steady, running can be more stable and faster.


4.Humanized automatic control design:


Adopts the single servo control of Y axis on both ends of the lead screw, that guarantee the synchronous movement of two lead screw.


Two UV LED lamps, the drying speed is faster and it can achieve bidirectional printing.


Two lead screw guide rail of Y axis, transmit stably, and Y axis motion more accurate, the print error less than 0.01mm.



Anti-collision device: when the print head strikes the media, it will stop, and the print head as well as carriage can be protected.
Contact information




0086 13925228627

Skype: alia_printer


Emergency back-up power supply: When the power is turned off suddenly, the printer can still maintain the normal operation of negative pressure system, and it will be engaged in work quickly once the power is turned on. The 24 hours*7 days production can be achieved.
Automatic measurement of media thickness:The printer automatically measure with senses distance nozzle and media, which eliminate the procedure that we measure thickness by ourselves. What's more, it saves our time and improves our work efficiency.
Contact information




0086 13925228627

Skype: alia_printer








Printer model

YD3200-KC   Alia Whatsapp/wechat:0086 13925228627

Print head


Number of head

4-8 pcs (Optional)

Print resolution


Print width

3.2 m

Media type

Rigid and flexible sheet

Print width

50 mm

Special ink

UV white ink


Print speed




High-speed mode

Single row  80 sqm/h;Double row  150sqm/h

Normal mode

Single row  60sqm/h;Double row  110sqm/h

High resolution mode

Single row  40 sqm/h

Double row  70sqm/h


Rigid material:glass,acrylic,wood,metal plate,PVC sheet,Corrugated board, reflective film, corrugated board. Flexible materials:leather,wall paper,advertising cloth,car sticker etc.

Ink type

Environmental UV curing ink(NO VOC)

Ink color

C,M,Y,K,LC,LM (Optional)

Image Format


Printer weight


Printer size

4.5m(length) × 2.1m(width) ×1.7m(height)

Power requirement

220VAC (±10%) Simplex printing,50 / 60 HZ, 7.5 KW (32A)


Working environment

Individual,clean,Low Dust,little sunshine,and Ventilated workshop,

Environment temperature:18º~30º (64º~86º) relative humidity:30%~70%(Non-condensing)Ventilation: Recommended use overhead exhaust fan, exhaust 600 cfm



Company Information

A leading manufacturer of UV based printers in the world since 2001. Head company in HongKong – YUEDA INTERNATIONAL (HONGKONG) INDUSTRY CO., LIMITED has been successfully able to sell more than 50 countries. The company has the necessary experience and the in house expertise to support printing applications in varied industry segments like Glass, Ceramic tiles , Glass,Wood, ACP, Signage, etc.


We are looking for agents now. no matter where are you from,

welcome to join us, pls contact Alia:
whatsapp/wechat: 0086 13925228627
