Quick Details

  • Type: Inkjet Printer
  • Condition: New
  • Plate Type: Flatbed Printer
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Yotta
  • Model Number: YD3200-RC
  • Usage: Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer, Tube Printer, uv hybrid printer
  • Automatic Grade: Automatic
  • Color & Page: Multicolor
  • Voltage: 110-220V 50*60HZ
  • Gross Power: 7500W
  • Dimensions(L*W*H): 4500*2100*1700mm
  • Weight: 1600KGS
  • Certification: CE, SGS
  • After-sales Service Provided: Overseas service center available
  • Keyword: uv hybrid printer
  • Print head: Industrial Ricoh Gen5 Print Head
  • Number of nozzles: Single row 4,5,6,7,8
  • color system: C,M,Y,K,LC,LM (Optional)
  • Printer size: 4500*2100*1700mm
  • Print width: 3200mm
  • Print height: 50 mm
  • Image Format: PDF,JPEG,TIFF,EPS,AI etc
  • ink type: high quality imported UV ink
  • curing systerm: UV led lamp

Packaging & Delivery

Packaging Details: wooden case Package
Delivery Detail: 3-5days for Test and package



  Yotta wide Format UV   Hybrid Vinyl Printer

Product Description











YD3200-KC Hybrid UV Printer printer printing good effect and more outstanding,welcome to visit our factory to see our actual printing effect.



Specification





Printer model

YD3200-KC   Sunny Whatsapp/wechat:0086 13925228630

Print head

KM1024i

Number of head

4-8 pcs (Optional)

Print resolution

720*1440dpi

Print width

3.2 m

Media type

Rigid and flexible sheet

Print width

50 mm

Special ink

UV white ink



Print speed







High-speed mode

Single row  80 sqm/h;Double row  150sqm/h

Normal mode

Single row  60sqm/h;Double row  110sqm/h

High resolution mode

Single row  40 sqm/h

Double row  70sqm/h

Application

Rigid material:glass,acrylic,wood,metal plate,PVC sheet,Corrugated board, reflective film,

 corrugated board. Flexible materials:leather,wall paper,advertising cloth,car sticker etc.

Ink type

Environmental UV curing ink(NO VOC)

Ink color

C,M,Y,K,LC,LM (Optional)

Image Format

PDF,JPEG,TIFF,EPS,AI etc

Printer weight

1600KG

Printer size

4.5m(length) × 2.1m(width) ×1.7m(height)

Power requirement

220VAC (±10%) Simplex printing,50 / 60 HZ, 7.5 KW (32A)



Working environment

Individual,clean,Low Dust,little sunshine,and Ventilated workshop,

Environment temperature:18º~30º (64º~86º) relative humidity:30%~70%(Non-condensing)Ventilation: Recommended use overhead exhaust fan, exhaust 600 cfm







YD3200-KC hybrid UV Printer adopts original imported KM1024i(14pl) print head, and it can print onto super huge flex materials which maximum print width 3200mm and thickness within 50mm. The materials including paper, PVC, plastics, leather, film,PP, banner and so on. the print speed is fast and can achieve mass production.





  Feature



1. Internal heated industrial print head:

Brand new gray-scale degree KM1024i internal heated industrial print head, gray scale KM1024i (14pl 12kHz) industrial print head, YD3200-KC is widely used in printing industry like Large-scale outdoor advertising . Super slim and space-saving shape of the print head improves print quality and makes the printer design more exquisite. 4-8 pieces of KM1024i heads you can choose. The print resolution is high, the print speed is fast, the ink droplet is more concentrated and the colors are brighter.









The machine structure is reasonable, the whole steel frame structure adopt tempering treatment materials, stable and reliable, good toughness, high strength, wear-resisting, anti-collision anti-deformation, that protect the printers from deformation caused by the long distance transportation and shipping jounce.



Whole steel frame structure tempering treatment,which adopt dual guide rail steel frame structure,print head can be more steady, running can be more stable and faster.



Humanized automatic control design:



Adopts the single servo control of Y axis on both ends of the lead screw, that guarantee the synchronous movement of two lead screw.



Two UV LED lamps, the drying speed is faster and it can achieve bidirectional printing.



Two lead screw guide rail of Y axis, transmit stably, and Y axis motion more accurate, the print error less than 0.01mm.



1.High speed printing: 16 pieces of KM1024 print heads can realize 72 sq.m/h under 4 pass


2.9 colors technology: CMYK LC LM White Varnish Primer, unique primer printing function is the best feature for printing on glass and ceramic tile


3.Multifunctional printing: it has all the advantages of dedicated UV flatbed printer, plus remarkable roll to roll function


4.Three layer printing: special technology of controlling print heads to realize “color-white-color” and “white-white-color” 3D printing.


5.Dual white printing: remarkable dual white printing technology


6.White printing: with best rip software caldera, many applications for white color such as overlay white, underlay white, fill white and spot white can be adopted on transparent materials to realize elegant appearance.


7.The carriage can start printing at either end on Y-direction, that is, it can print forwards and backwards, saving much time and raising productivity to a great extent


8.Automatic height detection: the maximum print thickness is 100mm, the height can be adjusted to appointed position automatically.


9.Automatic capping device: practical capping device ensures convenient maintenance



10.Special sectional vacuum suction: separate sectional vacuum suction effectively avoid print materials getting twisted.



11.Stop valve: Practical stop valves are installed in the carriage to prevent ink from dropping, electronic valves are also available



12.Locating pin: locating pins can be installed on the table of the printer for aligning, vertical printing and repeat printing are very convenient.



13.Anti-static function: anti-static device can be installed on the printer to eliminate static, misting can be avoided.



14.Anti-crash design: it can avoid any accident caused by carriage crash, effectively protect print heads.



15UV light shield design: effectively protect operator



16.Constant temperature in the ink tank: making sure it can print in a cold room.



17.Pneumatically controlled waste ink container

Packaging & Shipping

 Wooden case







Application fields:



Rigid materials:glass,ceramic,metal plate,wood,data plate.acrylic panel,KT board,PVC sheet,melamine sheet,marble board,etc.

Flexible materials: paper, PVC, plastics, leather, film,PP, banner,etc.





banner Printing sample










Company Information

A leading manufacturer of UV based printers in the world since 2001. Head company in HongKong – YUEDA INTERNATIONAL (HONGKONG) INDUSTRY CO., LIMITED has been successfully able to sell more than 50 countries. The company has the necessary experience and the in house expertise to support printing applications in varied industry segments like Glass, Ceramic tiles , Glass,Wood, ACP, Signage, etc.





 Exhibition







Our Services



1)One Year Warranty and lifetime after-sales service;

2)Overseas service provided;

3)We have our OWN R&D Department and professional after-sales Team.



Any inquiry, please feel free to contact Kate.Lu:





FAQ

Why select us:



Perfect quality along with competitive price
Since we are a few manufacturers of UV flatbed printer in China with many years production experience, we can provide the printer with excellent performance & direct price. You will enjoy our one-stop survice.





Higher speed plus higher resolution
Konica printhead with 1024i 12PL nozzle is used to support you with high speed printing and higher resolution(Max resolution can be up to 1440dpi*1440dpi





Ideal Transmission System
USB optical transmission, interference, to avoid printing garbage.





More application
Application areas includs:Decoration industry, glass industry;Sign industry;Exhibition industry;Leather textile printing industry, etc.


Printed materials could be:Glass, ceramic tile, ceiling, aluminum sheets, wooden sheets, billboards, acryl sheets, KD board, Plexiglas, foam board & flexible media like wall paper, glistening film, canvas, carpet, leather, paper sheets, and so on.







 Quality control:
